A compact hydraulic press for 7 mm KBr pellets in transmission FTIR — up to 2 tons of pressure in a small, portable benchtop format.
| Configuration | Mini KBr Press |
|---|---|
| Family | mini |
| Pressure range | 0–2 T (30 MPa) |
| Piston diameter | 28 mm (d) |
| Pressure stability | ≤ 1 MPa / 10 min |
| Workbench diameter | Ø45 mm (D) |
| Number of columns | Two |
| Working space | 54 × 55 mm (M × N) |
| Dimension | 100 × 220 × 220 mm (W × L × H) |
| Weight | 4.8 kg |
Overview
This mini pellet press is a compact and reliable laboratory hydraulic press designed for efficient KBr pellet preparation in FTIR analysis. Built for routine laboratory use, it delivers consistent pressure performance in a small, portable format, making it ideal for research labs, quality control environments, and educational institutions. Capable of producing uniform 7 mm KBr pellets with high optical clarity, this handheld pellet press applies up to 2 tons of hydraulic pressure, ensuring repeatable and high-quality results for transmission FTIR spectroscopy.
Technical data
Values as published for this model. Where a figure needs confirmation against the current datasheet it is marked accordingly.
| Configuration | Mini KBr Press |
|---|---|
| Family | mini |
| Pressure range | 0–2 T (30 MPa) |
| Piston diameter | 28 mm (d) |
| Pressure stability | ≤ 1 MPa / 10 min |
| Workbench diameter | Ø45 mm (D) |
| Number of columns | Two |
| Working space | 54 × 55 mm (M × N) |
| Dimension | 100 × 220 × 220 mm (W × L × H) |
| Weight | 4.8 kg |
We supply a user specification sheet for every model on request, together with die set compatibility and accessory options.
Compatible accessories
Every model in the range accepts circular, square, splitable and heatable Imperial die sets.
Standard (circular)
Designed for producing high-quality pressed pellets for laboratory analysis, including FTIR (such as KBr pellets) and XRF applications. With precision-engineered components and mirror-polished pressing surfaces, they ensure smooth, uniform pellets and reliable analytical results. Available in diameters from 2 mm to 150 mm.
300 °C – 500 °C, with temperature controller
Designed for pellet preparation under controlled heating conditions, where temperature plays a critical role in pellet quality. Supplied with an integrated temperature controller, they enable precise heating during pressing to enhance pellet uniformity and bonding.
Fast demoulding and non-circular geometries
Splitable die sets give fast, easy demoulding for complex or delicate pellets. Square die sets support non-circular sample geometries required in specialised testing.
40 mm, with steel ring
Ring die sets provide precise and uniform pellet formation for FTIR and XRF sample preparation, holding the sample in a defined steel ring during compaction.
